    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    Ask Lasest Price
    Brand Name : Bitvisus
    Model Number : BIT-MSE-8K60-204HD
    Certification : CE、FCC、GB
    Price : 500
    Payment Terms : T/T
    Supply Ability : 1000
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    Product Overview

    Professional 8K60 Multi-Screen Processor for Industrial-Grade Performance The BIT-MSE-8K60-204HD is an industrial-grade video wall processor engineered by Bitvisus to meet demanding 4K60 multi-desktop operations and multi-channel display needs. Supporting 2× 8K inputs (HDMI/DP selectable) and 4× 4K60 HDMI outputs, it delivers ultra-clear, fluid visuals across ultra-high-definition large screens or standard monitors. Ideal for mission-critical applications including control rooms, exhibition halls, virtual reality setups, and multi-screen LCD/LED displays.

    Product Characteristics
    ✅ Ultra-High Resolution & Flexibility
    Dual 8K Inputs: 2× independent 8K ports (HDMI or DP selectable), supporting up to 7680×2160@60Hz per input. Quad 4K Outputs: 4× HDMI 2.0 outputs @3840×2160@60Hz, compatible with all mainstream displays.
    ✅ Seamless Multi-Screen Control
    Zero-Latency Splicing: Supports 1×2, 2×2, or 1×4 layouts for pixel-perfect 4K60 video walls without stretching or distortion. Real-Time Processing: All-hardware architecture ensures ultra-fast operation with no lag (no software dependency).
    ✅ Industrial-Grade Reliability
    16KV Super Anti-Static Protection: Withstands harsh electrical environments. Advanced Thermal Design: 18W thermal-conductive material + internal heat dissipation + overheating protection for 24/7 stable operation. Anti-Interference Shielding: Ensures signal integrity in complex setups.
    ✅ Efficiency & Compatibility
    Low-Power Design: Energy-efficient (18W TDP) and eco-friendly. Bitvisus OpenWindow Software: Enables 8K60 multi-window display with drag-and-control flexibility. Parallel Operation Mode: Guarantees uninterrupted large-screen display during maintenance.
    ✅Applications
    Command & Control Centers Multi-Channel 4K60 Projection Systems Exhibition Halls & Digital Signage Virtual Reality (VR) Environments LCD/LED Video Walls

    Product Specifications
    Product NameBIT-MSE-8K60-204HD
    Input interface type2XHDMI 2.1,2xDP 1.4(Copper wire≤3M)
    HDCP2.2
    Input interface maximum video pixel frequency1200MH
    Maximum resolution8192x2160P60
    Color formatRGB444,YUV444,YUV422
    Output interface type4XHDMI 2.0(Copper wire≤10M)
    Output interface maximum video pixel frequency600MHz
    Output resolution4096x2160P60,3840x2160P60,3840x2400P60,2560x1600P60,2560x14400P60,1920x1080P120,1920x1200P120,1920x1080P60,1920x1200P60
    Color depth8bit
    Audio3.5MM audio separation, HDMI audio follow out
    Power supplyDC12V/5A
    Power comsumption20W
    Storage/working temperature- 10 to 50 º C/0 to 50 º C
    Product sizeLXWXH:290mmx143mmx35mm
    Package sizeLXWXH:360mmX215mmX70mm
    Product weigh1.2KG
    Packing weight1.7KG
    Accessories list1 X 12V5A power adapter, 2 xHDMI 2.1 cable or DP1.4 cable
    After-saleswarrantyAfter-sales service 3-year warranty


    Features at a Glance

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander


    Company Profile

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander

    8K60 Large Screen Parallel Use Multi-Monitor Splitter 2-in 4-out Multi-Screen Viewer 2x2 Pixel-to-pixel Multi-Screen Expander


    FAQ


    Why Choose Bitvisus ?

    1.We have our own warehouse, which can ensure us of shipping out orders within 48 hours after payment(weekends and holidays excluded).
    2. OEM/ODM offered for our customers.
    3.We have various pruduct that may suit for you, such as     Video Wall controller, Multiscreen Expander, Multiviewer, Embeded Projector Fusion and so on, which proves that our company has sufficient R&D experience and product quality assurrance.
    Shipment & payment
    1.T/T, Visa, PayPal, Western Union, L/C available.
    2.DHL, UPS, EMS, FedEx, Air freight, Sea freight supported.
    How to order?
    1. Please send us an email or chat with us via TM, WHATS UP, SKYPE and let us know your requirements for order details.
    2. We will provide a proforma invoice to you based on your order requirements.
    3. Please check the PI, if everything is OK, we will deliver the goods to you as soon as possible after receiving your payment.
