4K60 150m HDBaseT Extender Support One Loop Out Audio Extraction HDMI Extender IR/RS-232/CEC Control Cat6 HDMI Extender

Product Overview

4K EDID KVM USB Fiber Optic HDMI Extender

☞Compatible with HDMI 2.0b, HDCP 2.2/HDCP 1.4 and DVl 1.0;☞Support 18Gbps bandwidth;
☞The input and output extension distance can reach 120 meters / 150 meters and the supported resolution can reach 4K2K/1080P;
☞Support 1 HDMI loop output (transmitter);
☞Supports de-embedding source device audio to analog stereo
output(receiving side);
☞With bi-directional IR, RS-232 and CEC pass-through;
☞Supports HDR, HDR 10+, Dolby Vision and HLG functions;
☞Support PoC (Power over Cable) function;
☞Reasonable design, easy to install.

⇒Welcome to contact us to consult about the products required by
your project!

Product Specifications
Input
Transmitter(TX)1 xHDMI IN [ Type A,19- pin female];1 x SERVICE[ Mini-USB ,upgrade
port]
Receiver(RX)1 xHDMI IN [ Type A,19- pin female];1 x SERVICE[ Mini-USB ,upgrade
port]
Output

Transmitter(TX)1 xHDMI OUT [ Type A,19- pin female];1 x HDBT OUT[ RJ 45, 8- pin
female]
Receiver(RX)1xHDMI OUT[ Type A,19-pin female]
Audio1 x AUDIO OUT[3.5 mm Stereo Mini- jack ]
Other






Supported resolutionSupported resolution can reach 4K2K/1080P
Input color depthRGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Transmission bandwidth18Gbps
Resolution/ Distance4K*2K, 120 meters
1080P, 150 meters
L /R audio forrmatPCM 2.0
Power supply

Input: AC 100-240V 50/60Hz
Output : DC 24 V/1 A (with locking terminal)
Specification
Operating temperature0'C-40'C/32F-104'F
After-salesservice1 year warranty

Features at a Glance

Company Profile

FAQ
Why Choose Bitvisus ?
1.We have our own warehouse, which can ensure us of shipping out orders within 48 hours after
payment(weekends and holidays excluded).
2. OEM/ODM offered for our customers.
3.We have various pruduct that may suit for you, such as Video Wall controller, Multiscreen Expander, Multiviewer, Embeded Projector Fusion and so on, which proves that our company has sufficient R&D
experience and product quality assurrance.
Shipment & payment
1.T/T, Visa, PayPal, Western Union, L/C available.
2.DHL, UPS, EMS, FedEx, Air freight, Sea freight supported.
How to order?
1. Please send us an email or chat with us via TM, WHATS UP, SKYPE and let us know your requirements for order details.
2. We will provide a proforma invoice to you based on your order
requirements.
3. Please check the PI, if everything is OK, we will deliver the
goods to you as soon as possible after receiving your payment.
